Overview

S2-FFT is a basic but effective software for quick analysis of measured vibration signals in the field.
It includes tools to inspect the collected time series, apply windows, filter the signals, compute the Fourier Transform and plot its amplitude and phase, pick the dominant frequency components, and check the collected signals for stationarity.

Which problem does it solve?
Whenever you need to quickly check the quality of data in the field or to manipulate signals either in time or frequency domain in a simple but effective way, you can use S2-FFT (either in stand-alone version or as S2-DDA add-on) for your vibration measurement and monitoring applications.

Which needs does it fit?
S2-FFT is a must-have basic tool for all vibration testing engineers to quickly check and analyze the recorded signals in any test or monitoring application.

What makes our software stand out from the competition?
S2-FFT is a light but powerful software for vibration signal data processing. Filtering and decimating your time series, finding the dominant frequency components in the signals, checking their stationarity are some of the tasks you can perform with S2-FFT.

Other strengths

• very affordable price;
• natively interoperable with S2-DDA;
• embedded into S2-DDA but also available in stand-alone format.

Data manipulation and signal processing

S2-FFT lets the users inspect time series, apply windows, filter the signals, and compute the Fourier Transform, the signals in terms of amplitude and phase in the frequency domain. S2-FFT, therefore, supports you with the identification of dominant frequency components and checking of signal stationarity.

Data exchange and interoperability

S2-FFT is natively interoperable and embedded with S2-DDA (INSERIRE LINK ALLA PAGINA RELATIVA).
In the stand-alone version, supported data formats are as follows:

• Data input: *.txt, *.csv, *.tdms, *.csv for dDAS, *csv for pdDAS , *.lvm, *.dxd
• Data processing results: *.txt
• Images and plots: *.bmp

Versions and licenses

For any inquiry about S2-FFT or to ask for a quotation, please contact us through the side buttons.

S2-FFT is available in a single version, and in the form of a permanent license.

System requirements

Minimum or recommended hardware requirements for S2-DDA include:

• 64-bit CPU;
• 8 GB RAM;
• Operating system: Windows 10 or higher (x64);
• Screen resolution: 1920 x 1080;
• Hard disk space: 300 MB;
• Active internet connection.

Flyer

More details about S2-FFT can be found in the document herein available for download:

Buy now - Software

If you are ready to buy S2-FFT, complete the form below to ask for a quotation and proceed to purchasing.
